GE IC697MDL750｜Series 90-70 Discrete Output Module｜
Series: GE Series 90-70 PLC, single slot
Type: Transistor DC Output, Source Output
Points: 16 points, 4 groups isolated, 4 points per group
Hardware without jumper, I/O address software configuration
Status: Discontinued, spare parts market circulating inventory/dismantled machine
Electrical parameters
Load voltage DC12-24V Operating voltage range DC10-30 VDC Rated current per point 0.5A/point Maximum current per group 2A (sum of 4 points) Surge current maximum 10A, 10ms On voltage drop maximum 1.2V Off leakage current ≤ 0.1mA Response time Open ≤ 1ms, Off ≤ 1ms Backboard 5V consumption 0.12A Fuse per group Built in 5A fast melting, fuse failure LED
isolation
On site side ↔ PLC Backboard: 1500V DC Isolation
Between groups: 500V isolation
LED and I/O mapping
Each channel has an independent output status LED and a common LED for insurance faults
Occupy 2 16 bit output words, 1 bit corresponds to 1 channel
Error proof keyway to prevent module misalignment
environment
Working temperature: 0 ℃~+60 ℃
Storage: -40 ℃~+85 ℃
Vibration: 2g, 10-500Hz
IP20， Used inside the rack
