ABB GFD563A102 3BHE046836R0102｜Excitation Controller｜
GFD563A102 3BHE046836R0102
Power supply specifications
Rack backplane bus power supply, rated 24VDC ± 15%, overall power consumption ≤ 4.8W
Hardware integration reverse connection, surge, overvoltage 36VDC protection
Fiber optic signal channel
Multi channel dual channel fiber optic transceiver port: downward transmission of PWM gate drive pulses issued by GCC960 main control; Collect fault and unit temperature feedback signals from GDD471A001
Driver board upwards
High and low voltage insulation isolation withstand voltage: 5kV AC/1min, completely isolated from high voltage power circuit interference
Onboard peripheral I/O terminals
Plug in green terminal block, integrated with multiple digital DI/DO: high-voltage cabinet door safety interlock, cooling fan start/stop/status, charging contactor, power unit over temperature alarm signal acquisition and output
Backplane communication
ABB dedicated high-speed internal backplane bus, directly connected to GCC960C102/GCC960C103 main control operation board, without independent Ethernet/RS485 external communication port
