ABB DAPC100 3ASC25H203｜Control Board｜

DAPC100 3ASC25H203

Function
1. High precision analog signal acquisition (basic core)
Equipped with 2 independent analog input channels, compatible with 4-20mA, 0-10V, 1-5V industrial standard transmitter signals (temperature, pressure, flow sensors)
16 bit ADC analog-to-digital conversion, low-noise filtering circuit, resistant to frequency converter and motor electromagnetic interference, ensuring stable measurement accuracy

2. High speed process operation control
Built in 32-bit 100MHz RISC processor, equipped with standard closed-loop PID control algorithm, can independently complete on-site process adjustment, reduce the computational load of CPU main controller, and support custom control logic programming

3. Multi protocol industrial communication relay
Integrated multi class communication interfaces, supporting Profibus DP, Modbus TCP, Ethernet protocols:
Connect the on-site sensors and drive devices downwards; Transmission of operational data and alarm information to DCS upper computer and PLC in both directions upwards
Realize multi device networking interoperability and unified access to central control monitoring screens

4. Full channel fault self diagnosis protection
Real time monitoring of channel disconnection, signal over range, board power short circuit, communication interruption; Faults can be quickly located and repaired by synchronously pushing alarm codes through onboard indicator lights and system backend, avoiding machine shutdown

5. System stability and supporting characteristics
Power supply: 24VDC standard industrial control power supply
Wide temperature operation: -25 ℃~+70 ℃, suitable for high-temperature power plants and humid chemical workshops
Modular direct insertion backplane installation, supporting non-stop replacement and maintenance
Built in circuit overvoltage and overcurrent protection, single channel failure does not affect the overall operation of the board
