GE IC660BBD025｜Genius I/O｜
1、 Channel configuration
Quantity: 16 independent I/O channels, 16 points per group
Mode: Each channel software can choose input (Sink)/output (Source)/tri state input
Wiring: Source type, common terminal 24/48VDC+
2、 Digital input (when channel is set as input)
Rated voltage: 24/48VDC (18-56VDC wide voltage)
Input impedance: ≥ 10k Ω
Response time: 1.7ms (basic)+software filtering (5/10/20/50/100ms)
High level: ≥ 15VDC; Low level: ≤ 5VDC
Diagnosis: Open circuit, short circuit, overheating, and three state fault detection
3、 Digital output (when channel is set as output)
Output type: MOSFET source type, high side switch
Rated voltage: 24/48VDC (18-56VDC)
Each current: 2A (continuous), surge 10A/10ms
Total output current: 16A (16 channels at full load simultaneously)
On delay: ≤ 1ms; Off delay: ≤ 2ms
Pressure drop: ≤ 2.0V@2A
Leakage current: ≤ 1mA (off state)
Minimum load: 50mA (enable No Load function when no load)
Maximum switching frequency: 1Hz (in high wave scenarios)
4、 Electrical and Isolation
Working voltage: 18-56VDC (nominal 24/48VDC), ripple ≤ 10%
Isolation strength: 1500VAC/1 minute (between modules, channel to ground)
Power consumption: typical 150mA, maximum 300mA (24VDC)
Power off hold: 10ms (data not lost in case of power interruption)
5、 Environment and Physics
Working temperature: 0 ° C~+60 ° C
Storage temperature: -40 ° C~+85 ° C
Relative humidity: 5% -95% RH (without condensation)
Vibration: 5-10Hz: 5.08mm displacement; 10–200Hz：1G
Impact: 30g (11ms)
Size (mm): 224 × 90.5 × 112.3
Weight: Approximately 1.8 kg
Installation: 35mm DIN rail or panel installation
Protection: IP20 (to be installed inside a protective cabinet)
6、 Communication and Diagnosis
Bus protocol: Genius Bus (dedicated twisted pair)
Topology: daisy chain, up to 32 nodes, up to 2km away
Diagnostic LED: module OK, I/O enabled, each channel status indicator light
Configuration: Handheld IC66 * HHM500 or Proficy ME software remote configuration
Compatibility: GE 90-30/70/90 series PLC, ABB DCS, third-party equipment
IC660BBD022
