GE DS3800XTFP1E1C｜Control Module｜
Function
Used for the fan out, distribution, and switching of thyristor trigger signals in the GE Mark IV gas/steam turbine control system.
Expand the trigger signal of the main control card into multiple channels, drive the power thyristor, and achieve speed regulation, excitation, or power control.
Provide signal isolation, terminal allocation, and system power distribution conversion.
hardware interface
Terminal block: 8 sets of red terminals, each with 12 circular ports; Identification: JS, JT, JY, JX, JR, JQ, JP, JN (including 2 sets of inductive load specific).
Connector: 1 6-pin white male socket (auxiliary power/signal).
Installation holes: 1 at each corner and 2 fixing holes at the bottom edge.
Parameter
Backplane power supply: 24 VDC ± 10%
Working temperature: -25 ° C~+70 ° C
Storage temperature: -40 ° C~+85 ° C
Humidity: 5% -95% (without condensation)
Insulation withstand voltage: 1500 VAC (between boards)
Weight: Approximately 0.2-0.5 kg
Scene
Distribution of thyristor trigger/drive signals in the GE Speedtronic Mark IV turbine control cabinet.
Signal conversion and power drive output of gas turbine and steam turbine control systems in power plants.
DS3800XTFP1E1C
