GE DS200TCPDG2BEC｜Power Distribution Board｜
Core parameters
Digital input: 16 channels, 24VDC, current sink/pull type
Digital output: 12 channels, 24VDC, 2A per channel (driving valves, pumps, alarms)
Signal filtering: adjustable from 0.1ms to 10ms (anti electrical noise and anti false triggering)
Communication bus: Mark V Local Bus (compatible with Speedtronic core)
Power supply: 18-36VDC, approximately 12W
Temperature: 0 ° C~+65 ° C (without fan)
Size/Weight: Approximately 118 × 105 × 48mm/0.3kg
Main functions
Signal acquisition and driving: Collect digital status such as valve position, pump status, limit switch, etc; Output 24VDC signal to drive relays, solenoid valves, and sound and light alarms.
System interface: Communicate with the Mark V core controller (such as 505D) through the Mark V local bus to achieve triple redundancy configuration (up to 3 blocks installed side by side).
Diagnosis and reliability: Supports self diagnosis, redundant switching, overcurrent/overvoltage protection, and adapts to critical operating conditions such as power plants, oil and gas, and cogeneration.
Typical Applications
Gas turbine/steam turbine control (10-100MW)
Combined cycle power plants, industrial cogeneration
Compressor anti surge, fuel/steam flow control
Generator/line signal interface (in conjunction with TCQA/TCQC board)
DS200TCPDG2BEC
