ABB 5SHX06F6004｜IGCT Thyristor Module ｜

5SHX06F6004

Core
Blocking voltage: 4500V
Continuous current: 600A (Tc=85 ° C)
Peak turn off current: 1800A
On state voltage drop: ≤ 2.5V @ 1800A
Shutdown loss: 12Ws @ 1800A, 2800V
Cooling: Double sided water cooling
Working temperature: -40 ° C~+125 ° C
Size/Weight: Approximately 240 × 200 × 40mm/2.8kg

Function
High voltage and high current switch
As the core power component of a 6kV medium voltage frequency converter, it is responsible for the on/off of rectification and inverter main circuits, and drives 5-15MW high-power motors (such as rolling mills, fans, and water pumps).
Integrated gate drive (fiber optic control)
Built in driver board, receives fiber optic signals to achieve high-speed and anti-interference on/off, suitable for medium pressure electromagnetic interference environment.
Reverse conduction (continuation) capability
Integrated anti parallel diode, supports four quadrant operation, adapts to motor feedback braking conditions, without the need for additional freewheeling modules.
Real time status monitoring and protection
Monitor junction temperature, current, voltage, and gate signal, integrate hardware protection for overcurrent, overvoltage, overtemperature, and gate fault, quickly block in case of abnormalities, and protect the module and the entire machine.
Fiber optic communication and fault reporting
By exchanging control commands, operational data, and fault codes with the main control through optical fibers, the system can achieve linked alarm and safe shutdown.
