GE Fanuc IC800SS1228R02‑CE｜ VersaMax 16‑Channel 24VDC Sourcing Digital Output Module CE Certified｜

GE Fanuc IC800SS1228R02‑CE is a 16‑channel sourcing digital output module belonging to the GE VersaMax I/O system, originally manufactured by GE Intelligent Platforms (Emerson).

This compact output module provides 16‑point 24 VDC sourcing transistor outputs for driving field actuators, indicators and solenoid valves. It snaps onto standard VersaMax base units for fast field installation. Each channel comes with individual LED status indicator for quick on‑site troubleshooting. Electrical isolation between field side and logic circuit improves anti‑interference performance in noisy factory environments.

Hardware specifications: Total 16 digital sourcing (NPN) output channels; nominal operating voltage 24 VDC, working range 20.4‑28.8 VDC. Maximum load current: 0.5 A per single channel, total module current 4 A. Surge current up to 2 A for 100ms for inductive load startup. 500 VAC isolation between field wiring and internal logic circuit. Per‑channel LED diagnostic indicators for output status and fault alarm. Mounting: snap‑in installation on VersaMax base racks. Certification: CE compliance. Operating temperature range: 0°C ~ +60°C.

Typical applications: automated production lines, packaging machinery, material handling equipment, HVAC control, water treatment, and retrofitting maintenance of existing VersaMax control systems.

Product status: Original OEM unit, manufacturer discontinued. We supply surplus new stock and fully tested used‑refurbished spare units. Warranty is available for all supplied items. Goods are ready for international shipment.

Frequently Asked Questions

Q1: What base unit does IC800SS1228R02‑CE work with? A: This output module needs to be installed on standard GE VersaMax base units such as IC200CHS series bases. It cannot run without matching base rack hardware.

Q2: What is the output type of IC800SS1228R02‑CE? A: It is sourcing type (NPN) transistor output, 24VDC. Suitable for connecting solenoids, signal lamps and other field actuators. It cannot directly drive high‑power AC loads.

Q3: Can I hot‑swap this module while PLC power is on? A: Hot‑swap is not recommended. Power‑off the backplane power supply before inserting or removing the I/O module to avoid hardware damage.

Q4: Why some output channels show abnormal LED status? A: Possible causes include overload on individual channel, short‑circuit in field wiring, or exceeding total module 4A current limit. Check field load and wiring first for troubleshooting.

Q5: Is IC800SS1228R02‑CE still in mass production by GE? A: This model has been fully discontinued by GE‑Emerson. We offer original surplus new stock and tested used‑refurbished spare parts for legacy system maintenance.

Q6: What is the maximum current per channel? A: Each channel supports maximum 0.5A load current. Total current for all 16 channels must not exceed 4A for the whole module.

Q7: Does this module support Genius bus or Ethernet Global Data communication? A: Yes, when assembled with complete VersaMax rack system, it supports Genius I/O and Ethernet Global Data communication according to system configuration.

Q8: What does the ‑CE suffix stand for? A: The suffix‑CE indicates this module meets EU CE certification requirements for industrial equipment.
