ABB DYSF118B 61430001-XG｜Communication Interface Module｜
DYSF118B 61430001-XG
1. System power supply
Power source: Cabinet backplane DYPS154C power board unified 24VDC power supply
Whole machine power consumption: ≤ 8.5W
2. Analog output channel specifications (8 independent channels)
Signal type (single channel software switching)
Current: 4-20mA/0-20mA DC; Load 0~1000 Ω
Voltage: 0-10V/1-5V DC; Load ≥ 10k Ω
Conversion resolution: 16 bit high-precision
Basic accuracy: ± 0.05% FS (25 ℃ room temperature); Full temperature range ± 0.1% FS
Signal response speed: ≤ 1ms (instruction to output stable)
Temperature drift coefficient: ≤ 50ppm/℃
3. Isolation and EMC protection standards
Inter group isolation withstand voltage: 2500V AC for 1 minute
Channel to ground isolation: 2000V AC
Electrostatic protection: ± 15kV air discharge/± 8kV contact discharge
Surge immunity: ± 2kV IEC 61000-4-5
Compliant with EN 61326-2-3 industrial electromagnetic compatibility standard
