Overview
The VMIVME-2170A is a double-height 6U VMEbus optically coupled digital output board developed by VMIC, later GE Fanuc and Abaco Systems. It delivers 32 optically isolated digital output channels to drive relays, indicators and low-power actuators in legacy VMEbus control systems.
The optocoupler barrier fully separates field wiring from the VME backplane, eliminating ground loops and protecting the VME host from voltage surges and electromagnetic noise in electrically noisy factory environments. It supports flexible configuration including positive/negative true logic, source or sink mode, and two selectable output current levels. The VMIVME-2170A works as a VME slave, operating within short I/O address space, and is widely used as drop-in replacement spare for end-of-life VME racks in power, aerospace and automated test equipment.
Key Features
- 32 optically isolated digital output channels
- Dual selectable output current: 2.5mA low-current mode or 300mA high-current mode per channel
- Optical isolation rating: 1kV continuous isolation, 6kV pulse withstand
- Configurable logic polarity: positive true or negative true
- Source / sink output capability; field-installable pull-up resistors
- External pull-up voltage input for maximum isolation performance
- VMEbus slave interface supporting D08 / D16 data transfers, max 250ns access time
- 14-bit board address selection via on-board DIP switches
- Supports supervisory or nonprivileged short I/O access via jumper setting
- 6U double-height Eurocard form factor for standard VME chassis
- Compact front panel connector for field wiring
- Designed for long lifecycle legacy VME system maintenance and retrofit
Technical Specifications
表格
| Parameter | Details |
|---|---|
| Model | VMIVME-2170A (Part #: 332-102170-110) |
| Original Manufacturer | VMIC / GE Fanuc / Abaco Systems |
| Product Type | VMEbus 32-Bit Optically Isolated Digital Output Board |
| Number of Output Channels | 32 optically isolated outputs |
| Output Current | 2.5mA (low) / 300mA (high) per channel |
| Normal Mode Output Voltage | Up to 30VDC |
| Isolation Rating | 1kV continuous; 6kV 1-second pulse isolation |
| VMEbus Transfer | D8, D16, short I/O addressing |
| Maximum Access Time | 250 ns |
| Logic Polarity | Jumper configurable: Positive True / Negative True |
| Output Mode | Source or sink configurable |
| Form Factor | 6U Double Height VME Eurocard |
| Operating Temperature | 0°C ~ +70°C |
| Storage Temperature | -40°C ~ +85°C |
| Humidity | 20% – 80% RH, non-condensing |
| Power Supply | +5V DC from VME backplane |
| Condition | Discontinued original hardware; refurbished & fully tested units available |
Applications
The VMIVME-2170A serves as critical spare parts for maintenance and upgrade of legacy VMEbus automation systems:
- Relay, indicator lamp and low-power solenoid control
- Power plant control systems and SCADA VME subsystems
- Aerospace & defence automated test equipment (ATE)
- Semiconductor manufacturing equipment VME control racks
- Industrial test benches and data acquisition systems
- Heavy machinery and process automation control cabinets
Why Choose VMIVME-2170A
Original VMIVME-2170A boards are end-of-production and new units are no longer available. Our refurbished VMIVME-2170A units undergo complete hardware inspection and full channel functional testing before shipment.
The optical isolation design is the core advantage: it breaks ground loops and blocks transient noise between field devices and the expensive VME backplane, greatly reducing system downtime. Engineers can select either low-current signal-level driving or high-current relay driving on the same hardware, which simplifies spare inventory management.
It is a direct drop-in replacement for original VMIC hardware without chassis or backplane modification. We provide datasheets, pinout diagrams and technical integration guidance. All units are packed in ESD anti-static packaging for safe international transit.
Order & Shipping
- Condition: Refurbished, fully tested VMIVME-2170A
- Stock: Available, quick dispatch
- Shipping: DHL, FedEx, UPS worldwide delivery
- Warranty: Limited warranty for tested refurbished units
- Contact us for stock availability, quotation and technical support
