MOTOROLA VME162PA-344E｜VMEbus Single-Board Computer｜

1. Processor
CPU: Motorola MC68040RC33A (68K architecture)
Main frequency: 33 MHz
Built in: Hardware Floating Point Coprocessor FPU
Bus: VMEchip2+Petra II second-generation ASIC bridge
2. Memory&Storage (Factory Standard)
DRAM system memory: 16MB parity check DRAM (344E high-end version, with a difference of 4MB/8MB)
Onboard SRAM: 512KB (battery backed up NVRAM)
Start Flash: 1MB NOR Flash
RTC real-time clock: battery power failure saving
3. VME bus
Standard VME32/VME64, 32-bit A32/D32
Support VME DMA, interrupts, and bus arbitration
4. Expansion (344E’s biggest feature)
4 x IndustriePack (IP) interface slots (single width IP module), expandable with AI/AO/DI/DO/serial/CAN and other I/O modules
5. Onboard interface (standard for PA version)
Ethernet: 10Mbps Ethernet (E-NET) (Non Gigabit)
SCSI: CSI-2 DMA interface
Serial port: 2-channel RS232 (SIO) EIA-232-D
Hardware watchdog, timer, reset button
6. Mechanical&Electrical&Temperature
Board type: 6U double high VME single slot
Power supply: VME backplane+5V, ± 12V
Working temperature: E Wide temperature: -40 ℃~+70 ℃
Weight: Approximately 1.4kg (3lbs)
