Precise Control:
Equipped with advanced signal processing technology and high measurement accuracy, the controller enables precise, real-time tension management for coil or strip materials. It effectively reduces issues such as coil breakage, shrinkage, or deformation during production, ensuring stable and efficient operation.

Easy Operation:
Features an intuitive multi-language digital display and simple configuration buttons, allowing operators to easily set parameters, monitor tension values, and check system status without complex setup procedures.

Easy Integration:
Compact design with DIN rail installation facilitates seamless integration into a wide range of industrial control cabinets, making it ideal for system upgrades or new automation projects.

Technical Specifications

Item	Specification
Power Supply	DC 24 V (18–36 V)
Power Consumption	7.5 W
Number of Sensors	2 weighing sensor inputs
Sensor Excitation Current	0.5 A rms, 330 Hz
Analog Output	1 voltage output (−5 V to +11 V), 1 current output (0–21 mA)
Optional Filters	15, 30, 75, 250, 750, 1500 ms
Display Type	Multi-language digital display (2 × 16 characters)
Tension Unit Display	N, kN, kg, lbs, N/m, kN/m, kg/m, pli
Protection Level	IP20 (DIN rail mounting)
Operating Temperature Range	+5 °C to +55 °C
Electrical Safety	Complies with UL508 industrial control equipment standards
Physical Dimensions	Approx. 160 mm × 160 mm × 120 mm (depending on specific packaging)
Weight	Approx. 0.8 kg
