ELAU ISH100/30044/0/0/00/0/00/01/00｜Servo Motor｜

All products on this website are discounted products, and market prices have been fluctuating. Please refer to customer service quotes for details. Pictures are not actual photos. Before placing an order, please confirm the model, product, price, and other detailed information with customer service. Both second-hand and brand new products are available for sale on this website. Please contact customer service for further communication.

ELAU ISH100/30044/0/0/00/0/00/01/00｜Servo Motor｜

ELAU ISH070/60022/0/1/00/0/00/00/00

Continuous rated torque: 2.5 Nm
Peak torque: approximately 8.75 Nm (3.5 times overload)
Rated speed: 3000 rpm
Maximum speed: 4000 rpm
Rated voltage: DC 560-680 V (high voltage direct current)
Rated current: approximately 3.6 A
Rated power: approximately 0.78 kW

Output shaft: Optical axis (without keyway)
Bearing: High precision maintenance free bearing
Protection level: IP54 (without shaft seal)
Cooling method: self cooling (natural air cooling)
Encoder: Multi cycle absolute value encoder (SinCos SKS 36)
Brake: No brake

Bus protocol: SERCOS III (Real time Ethernet)
Connector: Hybrid connector (power+signal integrated)
Control mode: position/speed/torque control

Working temperature: 0 ° C to+40 ° C
Storage temperature: -25 ° C to+70 ° C
Relative humidity: 5% to 95% (without condensation)

Adaptive controller: ELAU PacDrive C200/C400
Typical applications: Packaging machinery, food and medicine, high-speed multi axis synchronous equipment
