ABB DSQC202｜Robot Computer Module｜

DSQC202

Function
Robot program/motion algorithm storage carrier
Onboard RAM memory+EPROM solidified chip, storing robot motion trajectory program, coordinate system parameters, servo motion control algorithm, and I/O logic.
Power outage data power outage protection
Equipped with a built-in backup lithium battery circuit, the control cabinet maintains the program and zero point parameters in RAM without losing them after power failure; Battery failure can result in program clearing and loss of origin.
Backplane bus data exchange
Real time exchange of motion commands, position feedback, and fault diagnosis data with the robot’s main control CPU through a dedicated European backplane bus for the control cabinet.
Hardware self diagnostic verification
Automatically verify the memory chip when powered on, and the panel fault indicator light will sound an alarm when the memory is damaged or the battery is low voltage.

Parameter
Storage Configuration
Standard capacity 128KB/256KB RAM, EPROM firmware for firmware solidification system; Scalable memory chip expansion.
Mechanical and Electrical
Specification: Standard 6U European style card, size 233 × 160 × 20 mm, net weight 0.42kg
Power supply: DC24V power supply for control cabinet backplane, low-power design
Working temperature: -10 ℃~+50 ℃, industrial cabinet IP20 protection
Interface: Exclusive ABB robot backboard gold finger, no external serial/network port
indicator light
Board side LED: power ready, memory running, battery low voltage, storage fault status indication with 4 channels.

ABB DSQC202｜Robot Computer Module｜
