Overview

The CI869 Communication Interface enables communication between the AC 800M controller network and Advant Fieldbus 100 (AF 100) systems.
It acts as a slave module, providing reliable and redundant communication when used together with two CI869 units. This setup is typically required when the AC 100 OPC Server runs in the Connectivity Server with an AF 100 hardware interface (CI527A) installed in the same node.

Features and Benefits

Reliable integration: Connects AC 800M controllers to Advant Fieldbus 100 networks.

Redundant communication: Supports Advant Fieldbus 100 redundancy using dual CI869 modules for enhanced system availability.

Hot-swappable design: Allows replacement without system shutdown, minimizing downtime.

Comprehensive redundancy: Supports both module and line redundancy, ensuring communication reliability.

Seamless OPC server operation: Designed for use with the AC 100 OPC Server and CI527A interface in the same node.

Industrial durability: Compliant with G3 corrosion protection and suitable for harsh environments.

Easy installation: Compact form factor with twisted pair connection for fieldbus communication.

Technical Data

Parameter	Description
Communication Protocol	ABB Advant Fieldbus 100
Role	Slave
Transmission Speed	1.5 Mbit/s
Line Redundancy	Yes
Module Redundancy	Yes
Hot Swap	Supported
Max Units on CEX Bus	12
Connector Type	Twisted Pair (TWP)
Typical Power Consumption	24 V DC, 160 mA
Used with HI Controller	Yes

Environmental and Certification Data

Specification	Details
Operating Temperature	0 to +55 °C (+32 to +131 °F)
Storage Temperature	-40 to +70 °C (-40 to +158 °F)
Corrosion Protection	G3 (ISA 71.04)
Protection Class	IP20 (EN 60529 / IEC 529)
CE Marking	Yes
RoHS Compliance	–
WEEE Compliance	Directive 2012/19/EU

Mechanical Data

Parameter	Value
Width	59 mm (2.3 in.)
Height	185 mm (7.3 in.)
Depth	127.5 mm (5.0 in.)
Weight (incl. base)	700 g (1.5 lb)

Summary

The CI869 provides a robust and redundant interface solution for linking AC 800M controllers to Advant Fieldbus 100 networks. Its support for redundancy, hot swapping, and G3-rated environmental protection ensures reliable operation in demanding industrial applications.
