Honeywell CC-IP0101｜Fieldbus Module｜

All products on this website are discounted products, and market prices have been fluctuating. Please refer to customer service quotes for details. Pictures are not actual photos. Before placing an order, please confirm the model, product, price, and other detailed information with customer service. Both second-hand and brand new products are available for sale on this website. Please contact customer service for further communication.

Honeywell CC-IP0101｜Fieldbus Module｜

1. Power supply and power consumption
Working power supply: DC 24V (18-30V wide voltage), provided by rack redundant power supply
Rated current: 0.32A
Maximum power consumption: ≤ 7.7W
Electrical isolation: fully isolated input/output, strong anti-interference ability
2. Processor and computing power
Processor: PowerPC 8270 32-bit RISC architecture, with a clock speed of 25MHz
System memory: 512KB Flash+455MB RAM
Control cycle: 10ms/20ms optional, deterministic control execution environment (CEE)
Control capability: Supports redundant I/O links, with a maximum of 80 I/O modules mounted on a single controller
3. Pulse counting function (core difference point)
Number of channels: 8 independent high-speed pulse counting channels
Input signal type: NPN/PNP open collector, differential pulse, TTL level
Counting modes: increasing/decreasing/bidirectional orthogonal counting, frequency measurement, period measurement
Maximum input frequency: Single channel 1MHz; Four channels working simultaneously with a total frequency of ≤ 2MHz
Count range: 0 to 99999999 (32-bit unsigned integer)
Timing resolution: 1 μ s to 999999.999s (configurable for 1 μ s/10 μ s/100 μ s/1ms, etc.)
Counting accuracy: ± 1 counting pulse
Fault tolerant design: Channel level fault isolation, single channel faults do not affect other channels
4. Communication interface
Main communication: Dual redundant I/O Link bus (connecting field I/O modules)
Extended communication: Ethernet RS-232、RS-485， Supports Modbus RTU/TCP, EtherNet/IP
5. Redundancy and Diagnosis
Redundancy support: Module level 1:1 hot redundancy, switching time ≤ 10ms
Fault diagnosis: channel fault, count overflow, communication fault, power failure, diagnostic coverage rate ≥ 99.5%
Alarm methods: local LED (power/operation/fault/redundancy), cabinet dry contacts, upper computer alarm
