ABB 500CPU05 1MRB150081R1/E｜Control Module｜

500CIM05 1MRB150077R1/B

1. Core parameters (can be directly sent to customers)
Processor: 32-bit ARM Cortex-A9, 1GHz, with FPU floating-point unit
Program memory: 16MB Flash (expandable with SD card)
Data memory: 512MB DDR3 RAM
Processing speed: Boolean instruction ≈ 0.05 μ s
Maximum I/O: up to 8192 digital inputs, 2048 analog inputs
Communication interface:
2 x Ethernet (10/100/1000Mbps)
1 × RS485 serial port
Supports PROFINET, EtherNet/IP, Modbus TCP, OPC UA, IEC 61850 ABB Group
Local display: LCD screen+operation buttons (can directly view status and change parameters)
Power supply: 24VDC (20.4-28.8V), power consumption * * ≤ 20W**
Working temperature: -25 ° C~+70 ° C
2. Main functions
Medium to large scale system controller: capable of complex logic, high-speed sequential control, multi loop PID, data acquisition and computation.
High speed multi protocol communication: Dual network ports can be used for redundancy, connecting SCADA, HMI, frequency converters, and instruments, with full coverage of power/industrial protocols for ABB Group.
Local visualization and maintenance: with LCD and buttons, it can view the running status, faults, and modify parameters without the need for a computer; SD card facilitates program backup/recovery.
High reliability and scalability: Backplane bus expansion, up to 16 I/O modules; Wide temperature range, anti vibration, suitable for power, metallurgy, water treatment, and large-scale production lines.
