ABB 086351-004｜Serial Pushbutton SP｜
086351-004
Function
Serial button scanning and encoding (main function)
Connect the matrix buttons/indicator lights on the control panel
Convert parallel button signals into serial data and upload it to the main control card (such as 086339-001)
Panel HMI interface
Support buttons for start/stop/reset/mode selection, etc
Driver panel LED status light
Bus communication
Communicate with the internal bus of the ECS system
Simplify panel wiring and reduce I/O point usage
Parameter
Interface: 30 pin DIN41612 (system side); Button matrix interface (panel side)
Power supply: 24VDC ± 10%
Working temperature: 0 ° C~+60 ° C (operating)
Button capacity: Supports up to 16/32 key matrix
Lamp driver: 24VDC LED, each channel ≤ 20mA
Application
Paper making HKQCS: Interface for paper machine operation panel/console buttons and status lights
Local control station of production line: machine side start/emergency stop/manual automatic button collection
