ABB UNS0884A-V1 3BHE004385R0001｜Control Module｜

UNS0884A-V1 3BHE004385R0001

Parameter
Measurement range: AC/DC 0-2000A (customizable)
Accuracy: ± 0.2% FS (high precision level)
Output signal: 4-20mA or 0-5V (optional)
Power supply: DC 24V ± 10%
Response time: ≤ 1ms
Working temperature: -40 ℃ to+85 ℃
Isolation withstand voltage: 2.5kV AC (primary secondary)
Protection level: IP65
Installation: DIN rail or panel installation
Weight/Size: Approximately 2kg; 230 x 165 x 50mm (length x width x height)

Features and Characteristics
Accurate measurement of high current: direct measurement of 2000A, suitable for high-power equipment, with an accuracy of 0.2 level.
Strong anti-interference: Multiple shielding, certified by EMC, suitable for strong interference environments such as frequency converters and motors.
Industrial grade reliability: overcurrent/overvoltage/short circuit protection; MTBF>100000 hours.
Standard signal output: 4-20mA directly connected to PLC/DCS, with strong compatibility.
Wide temperature range: -40 ℃ to+85 ℃, suitable for outdoor and harsh working conditions.

Application
Power generation: thermal power/hydropower/wind power – monitoring generator, transformer, and line current.
Metallurgy/Chemical: Electric arc furnace, electrolytic cell, large motor current monitoring.
Rail transit: traction converter, charging pile current measurement.
Industrial transmission: Overload and energy efficiency monitoring of high-power frequency converters and motors.
Energy storage/grid: battery energy storage systems, SVG/APF and other power quality equipment.
