GE Multilin SR750-P5-G1-S1-HI-A20-R Feeder Management Relay

All products on this website are discounted products, and market prices have been fluctuating. Please refer to customer service quotes for details. Pictures are not actual photos. Before placing an order, please confirm the model, product, price, and other detailed information with customer service. Both second‑hand and brand new products are available for sale on this website. Please contact customer service for further communication.

Product Overview

GE Multilin SR750-P5-G1-S1-HI-A20-R is a high-performance microprocessor-based feeder management relay belonging to the famous 750/760 series. It is designed for primary protection, metering, monitoring, control and automation of medium-voltage distribution feeders for utility substations, power plants and industrial power distribution networks.

Model suffix breakdown:

• SR750: Feeder management relay series
• P5: 5 Amp phase CT secondary current input
• G1: 1 Amp ground fault CT input
• S1: 1 Amp sensitive ground fault CT input for high-impedance grounded system
• HI: High wide-range auxiliary control power supply
• A20: Four programmable 4–20 mA analog output channels
• R: Drawout removable chassis construction

This relay integrates full suite of feeder protection elements including phase overcurrent, directional overcurrent, ground fault, sensitive ground fault, breaker failure, over/under voltage, over/under frequency, negative sequence and thermal overload protection. It supports FlexLogic™ custom programmable logic, fault waveform capture, sequence of event recording and multi-protocol serial communication for SCADA/DCS integration. GE has discontinued the SR750 series. We supply surplus and fully refurbished SR750-P5-G1-S1-HI-A20-R spare parts for legacy substation feeder cabinet maintenance, avoiding costly full system retrofit.

Key Features

✅ Comprehensive feeder protection: phase overcurrent 50/51, directional overcurrent, ground fault, sensitive ground fault, breaker failure, voltage & frequency protection ✅ P5 5A phase CT secondary input, compatible with standard 5A phase current transformers widely used in distribution substations ✅ G1 1A ground CT + S1 1A sensitive ground CT for detection of low-level ground faults ✅ HI universal high-range control power: 70–265V AC / 90–300V DC, 48–62Hz ✅ A20 option: 4 isolated programmable 4–20mA analog outputs to transmit electrical parameters to DCS or PLC ✅ R drawout chassis: hot removable without disconnecting field wiring, greatly reduce maintenance outage time ✅ FlexLogic™ customizable programmable logic for feeder automation, load shedding and interlock schemes ✅ Event recorder & oscillographic fault waveform capture for post-fault diagnostics and root cause analysis ✅ Multi-port communication: RS232, RS485, Modbus RTU, DNP3.0, IRIG-B time synchronization ✅ Built-in power metering for kW, kVAR, kWh, power factor and demand monitoring

Technical Specifications

• Model: SR750-P5-G1-S1-HI-A20-R
• Brand: GE Multilin / GE Vernova / GE Grid Solutions
• Product Family: 750/760 Feeder Management Relay
• Phase CT Secondary Input: 5A (P5)
• Ground CT Input: 1A (G1)
• Sensitive Ground CT Input: 1A (S1)
• Control Power (HI): 70–265V AC, 90–300V DC, 48~62Hz
• Analog Output: 4 × 4~20mA (A20)
• Mounting: Panel mount, drawout chassis (R)
• Operating Temperature: -40℃ ~ +70℃
• Humidity: 5% ~95% RH, non-condensing
• Protection Rating: Front IP54, rear IP30
• Certifications: CE, UL, IEC 60255

Applications

GE Multilin SR750-P5-G1-S1-HI-A20-R relays are widely deployed for medium voltage distribution feeder protection:

• Utility substation distribution feeders
• Power plant auxiliary medium voltage feeders
• Large industrial plant main distribution feeders
• Oil & gas plant power distribution feeders
• Mining heavy industry medium voltage feeders
• Backup protection for busbars, small transformers and short transmission lines
• Replacement spare parts for legacy GE SR750 feeder protection panels

Product Supply Information

We provide fully tested GE Multilin SR750-P5-G1-S1-HI-A20-R feeder management relays for global power and automation buyers. The SR750 series is discontinued by GE. Available stock includes surplus and refurbished units.

• Complete functional, protection logic and communication testing before shipment
• 12-month warranty
• Anti-static packaging, secure export carton
• Shipping options: DHL, FedEx, UPS, sea freight
• Trade terms: EXW, FOB, CIF, DDP

FAQ

Q1: What does -P5-G1-S1-HI-A20-R suffix mean?

A: P5=5A phase CT secondary; G1=1A ground CT; S1=1A sensitive ground CT; HI=high wide-range control power; A20=four 4–20mA analog outputs; R=drawout removable chassis.

Q2: Is discontinued?

A: Yes, GE Multilin has phased out the 750 feeder relay series. We supply surplus and fully tested replacement units for legacy feeder protection systems maintenance.

Q3: What is the difference between G1 and S1 for SR750?

A: G1 = standard ground fault CT input; S1 = sensitive ground fault CT input, used to detect low magnitude leakage ground faults in high impedance grounded distribution systems.

Q4: What is the advantage of R drawout chassis?

A: Drawout design allows technicians to extract relay unit for maintenance, testing or replacement without removing field wiring, minimizing substation downtime.

Q5: What communication protocols does SR750-P5-G1-S1-HI-A20-R support?

A: RS485 Modbus RTU, DNP3.0, RS232, plus IRIG-B time synchronization for accurate event timestamping.
