Key Technical Parameters
1. Power Supply Specifications

Input voltage: 200–250 VAC, 47–63 Hz

Output voltage: 24 VDC

Output current: 15 A

Rated power: 360 W

Power architecture: High-efficiency switching power supply with > 90% conversion efficiency

Application suitability: Capable of powering a broad range of industrial sensors, actuators, controllers, and auxiliary equipment

2. Communication & Interfaces

Supported protocols:

Profibus DP, communication speed up to 960 kbps

RS-485

Ethernet

I/O configuration:

16 digital inputs/outputs (DI/DO)

2 analog inputs/outputs (AI/AO)

Expansion:

Equipped with Mini PCI-E slot for extended communication modules or special-function interfaces

3. Environmental Adaptability

Operating temperature: –20°C to +70°C

Storage temperature: –40°C to +85°C

Protection rating: IP65, providing significantly improved dust-proof and water-resistant capability compared to typical cabinet-dependent IP20 modules

Application suitability:

Stable operation in harsh industrial environments including high-dust areas, humid zones, and wide-temperature outdoor installations

Core Functions

Real-time data acquisition: Temperature, pressure, equipment status, and other process signals

Precise control output: Supports remote device actuation and closed-loop industrial control

Electrical protection design:

1500 VAC input/output isolation

10 kA surge protection, suitable for grids with lightning risk or unstable power quality

Low ripple, high-stability output: Suitable for powering sensitive equipment (instrumentation, precision actuators, control circuits)

Typical Application Scenarios
Industrial Automation

Production line control

Multi-equipment coordination in manufacturing

Real-time equipment monitoring and process optimization

Energy and Power Systems

Power plant and substation equipment linkage

Control of static excitation systems, transformers, auxiliary generators

Energy management and device health diagnostics

Oil & Gas / Heavy Industry

Generator, compressor, and transformer operation control

Pipeline pressure/temperature monitoring with actuator feedback

Other Adaptable Scenarios

Robot system control platforms

Building automation and distributed facility management

Any environment requiring stable 24VDC power and mixed I/O for high-reliability operation

ABB PPD113B01-23-111000 3BHE023784R2330｜Central Control System Module｜
