Hardware Specifications

Item	Specification
CPU Type	PowerPC 405
Clock Speed	200 MHz
Memory	256 MB RAM, 512 MB Flash
I/O Configuration	64 Digital Inputs, 64 Digital Outputs, 16 Analog Inputs, 16 Analog Outputs

Communication Capability

Item	Specification
Supported Protocols	Ethernet, RS-232, RS-485, Profibus DP, Modbus TCP/IP
Network Interface	1 × 10/100M adaptive Ethernet port

Features

High Performance:
Equipped with a 200 MHz PowerPC processor and optimized control algorithms, the module achieves a cycle time as short as 100 μs, providing the performance needed for high-speed control and low-speed process control in parallel. It is especially suitable for high-power rectifier and real-time control applications.

Strong Compatibility:
The modular architecture allows seamless integration with existing automation systems. The design supports customization and expansion, making it adaptable to diverse industrial control requirements.

Easy Maintenance:
Installed on a standard DIN rail, the module operates without forced cooling. It supports optical link communication for high-speed data transfer between modules. Communication and I/O links can be flexibly configured, simplifying both installation and maintenance.

Application Fields

The module is suitable for a wide range of industrial automation and control applications, including:

Aluminum continuous rolling automatic control systems

Hot rolling conveyor roller automatic control systems

Initial rolling control systems for hot-rolled strip steel

Master-slave control for medium and thick plate secondary rolling mills

Direct torque control systems for continuous annealing or regression units

Engine test bench hot-break loading devices

Winch and hoist control systems

Leveling line electrical control systems
