ABB DSQC604 – Digital Input Module for IRC5

? Overview

The ABB DSQC604 is a dedicated digital input module for the ABB IRC5 robot controller. It is designed to interface with external sensors and provide reliable status feedback to the robot control system, enabling seamless integration with automation environments.

⚡ Core Parameters & Characteristics

• Module Type: Pure digital input (no output channels)

• Input Channels: 32 independent digital inputs

• Input Power Supply:

  • Nominal: 24 VDC

  • Range: 18–30 VDC (compatible with industrial power standards)

• Supported Signal Types:

  • PNP or NPN sensor inputs

  • Compatible with industrial proximity switches, photoelectric switches, and other discrete sensors

• Communication Interface: DeviceNet bus

  • Provides real-time communication with IRC5 controller

  • Ensures low-latency signal transfer

?️ Protection & Reliability

• Protection Class: IP20 (requires installation inside robot control cabinet)

• Operating Temperature: –5 °C … +55 °C

• Built-in Diagnostics:

  • Channel-level fault detection (short circuit, open circuit)

  • Fault reporting via IRC5 controller for rapid troubleshooting

  • Reduces downtime in industrial environments

? Typical Applications

• Centralized acquisition of digital signals from:

  • Proximity switches

  • Photoelectric sensors

  • Mechanical limit switches

  • Safety interlocks

• Used in robot-controlled production lines:

  • Automotive assembly

  • Material handling

  • Packaging & logistics

  • General factory automation

✅ Summary:
The ABB DSQC604 is a robust and reliable digital input expansion module tailored for IRC5 systems. With 32 input channels, flexible PNP/NPN compatibility, DeviceNet communication, and advanced fault diagnostics, it enables robots to safely and efficiently interface with external devices in complex automation setups.
