Name: GE DS200DCFBG2BNC MRP433745｜Mark V DC Feedback Power Board｜
SKU: 34514
Price: 2000.00 USD
Availability: InStock

Our company specializes in importing industrial control spare parts, and we can help you transfer most of them from abroad. Due to the wide variety of models, we were unable to upload physical pictures one by one!
If the model you need cannot be found in our store, please feel free to inquire at any time.

GE DS200DCFBG2BNC MRP433745｜Mark V DC Feedback Power Board｜

GE DS200DCFBG2BNC MRP433745｜Mark V DC Feedback Power Board｜illustration

Core parameters
Input voltage: 38-115VAC (powered by control power transformer)
Output power supply:
Control level:+5V, ± 15V, ± 24VDC (supplying power to the board/logic)
Cabinet fan: 115VAC
Monitoring signals: armature current/voltage, magnetic field current, AC side voltage/phase sequence, motor temperature, etc
Configuration components: 13 jumpers, 7 DIP switches (address/mode configuration)
Indication/protection: 2 red LEDs+1 neon light; 3 fuses, overcurrent/overvoltage/undervoltage protection
Size/Weight: Approximately 220 × 150 × 40mm/Approximately 0.8-1.5kg
Environment: Working at -40 ℃~+70 ℃; Storage -40 ℃~+85 ℃; Humidity 5% -95% (no condensation)
Compatible systems: DC2000, AC2000, CB2000, ME2000, EX2000 (excitation) FC2000、GF2000

Application scenarios
Gas/Steam Turbine Control (Power Station, Petrochemical, Large Industrial Drive)
Core power supply and monitoring for EX2000 excitation system and DC2000 DC drive system
Signal conditioning, power distribution, and fault diagnosis of the drive cabinet in the Mark V system

Characteristic
Integrated: power supply+monitoring+driving pulse circuit, reducing external wiring
Industrial grade reliability: Three proof coating, wide temperature design, suitable for harsh working conditions
Plug and play: standard Mark V rack mounted, directly connected to SDCC/LDCC control board
