Product Overview

The control panel/HMI is a versatile, high-performance human-machine interface designed for modern industrial automation systems. With a bright 7-inch TFT LCD display, powerful processing capability, and robust industrial protection, it enables efficient monitoring, intuitive operation, and reliable communication across various control environments.

Technical Specifications

Parameter	Specification
Product Type	Control Panel / HMI
Display Screen	7-inch TFT LCD color touchscreen
Resolution	800 × 480 pixels (WVGA)
Display Colors	16.7 million colors
Touch Type	Resistive touch – supports operation with gloves
Processor	ARM Cortex-A8
Memory	256 MB RAM, 512 MB Flash
Communication Interfaces	Ethernet (10/100 Mbit/s), USB 2.0 (Type A), RS-232, RS-485
Protection Level (Front Panel)	IP65 – dustproof and water-resistant
Operating Temperature	0 °C to +50 °C
Storage Temperature	–20 °C to +60 °C
Power Requirement	24 VDC (18–30 VDC)
Dimensions / Weight	[Specify if available]

Key Features

High-Definition Display:
The 7-inch TFT LCD touch screen offers 800×480 resolution and 16.7 million colors, ensuring vivid visualization of process data, alarm messages, and control interfaces.

Industrial-Grade Touch Control:
The resistive touchscreen allows accurate operation even when the user is wearing gloves, ideal for industrial environments.

Powerful Performance:
Built on an ARM Cortex-A8 processor with 256 MB RAM and 512 MB flash memory, providing fast, stable operation for complex HMI applications.

Comprehensive Connectivity:
Equipped with Ethernet, USB, RS-232, and RS-485 interfaces, allowing seamless integration with ABB PLCs, DCS systems, and other automation devices that support standard communication protocols.

Reliable Protection:
The IP65-rated front panel offers effective resistance against dust and water ingress, ensuring dependable operation in harsh or dusty industrial conditions.

Application Areas

This HMI is widely used across multiple industrial and infrastructure sectors, including:

Manufacturing and Power Generation – real-time monitoring and control of production lines and electrical systems.

Water and Wastewater Treatment – monitoring and operation of pumps, valves, and process parameters.

Food & Beverage and Pharmaceuticals – ensuring process consistency and regulatory compliance.

Chemical and Building Automation – providing intuitive visualization and control for complex systems.

It enables efficient data display, parameter adjustment, and alarm monitoring, improving operational efficiency and overall system reliability.
