WOODWARD 8200-150｜Turbine Control｜
Function
Drive object: Suitable for Woodward electro-hydraulic actuators, servo valves, proportional valves, output control current/voltage signals.
Control mode: Receive 4-20mA or voltage commands from speed controllers (such as 505, Peak 150), and drive the actuator in a closed-loop manner.
Protection function: Built in overcurrent, short circuit, and reverse polarity protection, suitable for harsh industrial environments.
Application
Small industrial steam turbine and gas turbine speed control system.
Engine/generator set actuator drive.
The matching drive for the old Woodward speed control system (such as the early version 505 and Peak150).
Parameter
Power supply: mostly 24VDC (some models support 12/24VDC wide voltage).
Output signal: 4-20mA or 0-10V analog, suitable for mainstream actuators.
Communication: In the early days, it was mostly hard wired I/O without native Ethernet/Modbus (requiring external modules).
Installation: rail or panel installation, compatible with standard control cabinets.
WOODWARD 8200-150｜Turbine Control｜
By structuring the information in this manner, the article provides a clear and organized understanding of input channels, transducer supply, and communication implementations in distributed control systems.
