Product Type: Tension Force Sensor (Pressductor Type)
Rated Load: 1.0 kN (1000 N)

Parameter	Specification
Rated Load	1.0 kN
Nonlinear Error	≤ ± 0.1 % FS (Full Scale)
Repeatability	≤ ± 0.05 % FS
Excitation Voltage	10 V DC (Typical)
Output Signal	Standard Analog Signal (Compatible with 4–20 mA or mV/V)
Material	Stainless Steel
Protection Level	IP67 (Dustproof, Waterproof, Corrosion-Resistant)
Connector Type	M12 Standard Connector
Cable Length	3 m (Customizable)

Core Features and Characteristics

High Measurement Accuracy
Provides precise tension measurement with a nonlinearity of ≤ ± 0.1 % FS and repeatability of ≤ ± 0.05 % FS, fully meeting the requirements of precision tension control in demanding industrial applications.

Advanced Pressductor® Technology
Incorporates ABB’s patented Pressductor® magnetostrictive technology, offering superior overload and impact resistance compared with traditional strain-gauge sensors. Ensures long-term stability without zero drift and minimal temperature influence, even under continuous operation.

Excellent Environmental Adaptability
Built with a sealed stainless steel enclosure (IP67) that provides effective dustproof, waterproof, and corrosion-resistant performance. Designed to withstand harsh operating environments such as high humidity, vibration, and mechanical shock.

System Compatibility
Supports direct integration with ABB PLCs or general industrial control systems. The standard analog output (4–20 mA or mV/V) enables simple, reliable connection to automation or tension control modules.

Typical Application Scenarios

Precision Coil Processing
Used in cutting, rewinding, and coating of low-tension materials such as films, thin papers, and fine cables to prevent stretching, deformation, or breakage.

Electronics and Textile Industry
Applied for tension monitoring during the production of fine metal wires, fibers, and non-woven fabrics, ensuring dimensional consistency and product quality.

Automated Closed-Loop Control
Serves as a high-precision force feedback element in tension control systems, enabling real-time dynamic adjustment for automated production lines requiring tight tension regulation.
