Product Features

Communication Protocol Support
Supports multiple industrial communication protocols, including IEC 61850, DNP3, and Modbus, enabling seamless communication with Remote Terminal Units (RTUs) and Supervisory Control and Data Acquisition (SCADA) systems. This ensures efficient data exchange, system interoperability, and smooth integration within complex automation networks.

Strong Compatibility
Designed for high adaptability, the module is compatible with a wide range of RTUs, SCADA systems, and other intelligent electronic devices (IEDs), meeting the interoperability requirements of diverse power automation systems.

High-Speed Communication
Provides data transmission rates of up to 19.2 kbps, ensuring fast, reliable data transfer and real-time response to system control and monitoring demands.

Reliable Industrial Design
Built for operation in harsh industrial environments, the module features robust resistance to temperature variations, humidity, and electromagnetic interference.

Operating temperature: –25 °C to +70 °C

Storage temperature: –40 °C to +85 °C

Relative humidity: 5%–95% (non-condensing)
This design ensures stable and continuous operation even under demanding field conditions.

Flexible Configuration
Configuration and parameterization can be performed via ABB configuration software or tools, allowing users to:

Set communication parameters, baud rates, and data formats

Define communication protocols and channel functions

Program communication tasks and customize data exchange between the control system and external devices

Technical Specifications

Parameter	Specification
Power Supply	24 V DC
Number of Channels	4
Communication Rate	Up to 19.2 kbps
Dimensions (W × H × D)	115 × 65 × 30 mm
Weight	0.4 kg
Operating Temperature	–25 °C to +70 °C
Storage Temperature	–40 °C to +85 °C
Relative Humidity	5%–95% (non-condensing)
