Core functionality
Thermocouple signal acquisition and conditioning
Support standard thermocouple types such as J/K/T/E/R/S/B
32 independent input channels, each with high-precision cold junction compensation (CJC)
Built in signal isolation, filtering, and linearization, resistant to strong electromagnetic interference on site
Discrete Quantity (DI) Signal Processing
Receive dry contact signals such as switches, relays, limits, and status feedback
Used for gas turbine start stop, valve position, protection circuit, alarm monitoring
system adaptation
Adapt to Mark VI/VIe controllers as signal interfaces between on-site sensors and controllers
Support redundant configuration to enhance system reliability
Parameter
Power supply: 24 VDC/48 VDC
Working temperature: -40 ° C to+85 ° C
Number of channels: 32 thermocouples/discrete input
Isolation: Electrical isolation between channels, strong anti-interference ability
Installation: Standard rack installation, compatible with TDBT base
Application
Gas turbine, steam turbine control system (start-up, load regulation, over temperature/over speed protection)
Power plant temperature monitoring (combustion chamber, turbine, exhaust, bearings, etc.)
Industrial process safety interlocking and status monitoring
