Technical Specifications

Applicable System: GE Mark VIe Speedtronic Turbine / Gas Turbine Control System

Associated Gateway Module: IS220PPRFH1B PROFIBUS-DP Master I/O Module

Signal Characteristics

Supported Signal Types:

4–20 mA current input

0–10 V voltage input

Channel Configuration:

8 analog input channels per terminal board

Electrical Isolation

Isolation Level:

2.5 kV AC isolation between channels and between field and system circuits

Effectively suppresses common-mode interference and ground loop effects

Power Supply

Power Input: 24 V DC

Supplied from the system power supply

Provides logic power for the terminal board

Connector Configuration

Field Wiring Interface:

Euro-style terminal block, 36-pin

Gateway Interface:

P1 50-pin communication connector for direct docking with the PROFIBUS gateway

Environmental Conditions

Operating Temperature: −40 °C to +70 °C

Storage Temperature: −40 °C to +85 °C

Humidity: 5% to 95% RH (non-condensing)

Mechanical and Installation

Dimensions (W × H × D):
Approx. 159 mm × 178 mm × 50 mm

Mounting Method: Surface-mounted

Cabinet Compatibility: Mark VIe standard control cabinets

Weight: Approx. 1.0 kg

Documentation

Reference Manual:
Mark VIe Terminal Board System Instruction Guide (GEH Series)

Core Features
High-Precision Signal Conditioning

Integrated filtering and amplification circuitry ensures accurate acquisition of 4–20 mA and 0–10 V analog signals, making the module suitable for critical measurements such as pressure, temperature, and process variables.

High-Level Electrical Safety Isolation

The 2.5 kV AC isolation design effectively isolates field wiring from control electronics, protecting the system from electrical noise and surges in harsh industrial electromagnetic environments.

PROFIBUS-DP Gateway Integration

Seamlessly interfaces with the IS220PPRFH1B PROFIBUS-DP gateway, enabling reliable, real-time data transmission over the PROFIBUS-DP communication protocol.

Visual Fault Diagnostics

Each analog input channel is equipped with an LED status indicator, allowing rapid identification of fault conditions such as open circuit, short circuit, or overcurrent, thereby reducing troubleshooting time and system downtime.

Scalable System Compatibility

Fully compatible with Mark VIe controllers and distributed I/O architectures. Multiple terminal boards can be deployed in parallel to meet large-scale analog signal acquisition and expansion requirements.
