Channel Configuration

Analog Outputs: 8 channels

Output Range:

Standard: 0–20 mA

Selected channels configurable to 0–200 mA via jumper

Adaptation & System Compatibility

Dedicated Interface: Compatible only with VAOC (Voltage Analog Output Control) I/O boards

Rack Capacity:

One VAOC rack supports up to 2 output boards

Expandable to a maximum of 16 analog output channels

Physical Interface & Installation

Field Connector: 37-pin latching industrial connector

Terminal Interface: 48-position screw terminal block

Mounting: DIN-rail installation

Maintenance: Supports hot swapping for online replacement

Signal Processing & Isolation

D/A conversion and output driving provided by VAOC

Integrated output current detection and feedback monitoring

Field-side to logic-side electrical isolation ≥ 1000 VDC

Power Supply & Operating Environment

Supply Voltage: 12–24 VDC

Operating Temperature: –20 °C to +60 °C

Humidity: 5%–95% (non-condensing)

Protection & Diagnostics

Overcurrent and short-circuit protection

Per-channel fault detection

Front-panel LED status indication for operational and fault states

Core Functions & Adaptability
Precision Current Output

Working in closed-loop current control with the VAOC module, the system delivers high-accuracy analog output suitable for servo valves, actuators, and regulating valves, ensuring stable and precise control performance.

Simplex-Dedicated Design

Optimized for simplex control architectures, the module communicates exclusively with VAOC boards, reducing system complexity and simplifying configuration, commissioning, and maintenance.

Coordinated System Operation

Must be used in conjunction with the Mark VI power supply module (e.g., IS200PSVOH1A) and the VAOC module (e.g., IS200VAOCH1A) to ensure stable power delivery, signal integrity, and reliable system operation.
