GE IS200DSPXH1CAA｜Digital Signal Processor Control Board｜
Core Functions
Real-time control algorithm execution
Signal acquisition and processing
ISBus communication management
Fault detection, diagnosis, and feedback
Drive control core interfacing with power modules and the control rack
Processor & Performance
60 MHz DSP core with ASIC hardware acceleration
Flash-based firmware storage
Supports high-speed current and voltage loop regulation
Control response time: < 100 µs
Communication Interfaces
Right-angle backplane connector (P1)
Two front-panel connectors
Vertical pin connectors compatible with Mark VI standard backplane
Supports ISBus redundant communication
Status Indication & Diagnostics
Two onboard LED indicators:
RUN: Board operating normally
FAULT: Power, communication, or core processing fault
Provides real-time visibility of board health and communication status
Power Supply Requirements
+5 V logic power supply
±15 V isolated analog power supply
High immunity to electrical noise and industrial power grid fluctuations
Mechanical Specifications
Standard 6U PCB form factor
Approximate dimensions: 22.9 cm × 33.0 cm
Compatible with Mark VI standard control rack rails
Environmental Specifications
Operating temperature range: –20 °C to +65 °C
Industrial-grade protective coating
Suitable for harsh environments such as power plants and metallurgical facilities
