Power supply specifications: Referring to the configuration of rack interface modules of the same brand and type, as well as 80165 series related modules, industrial rack interface modules are often compatible with industrial standard 24V DC power supply. It is speculated that the power supply voltage of this model is 24V DC ± 10% to adapt to the general power supply environment inside industrial control cabinets and reduce the impact of voltage fluctuations on signal transmission.
Isolation performance: As the core module that connects external devices and rack controllers, it is likely to have a safe isolation voltage of 1500V AC, which can reduce the risk of external signal interference and circuit failure, ensuring the electrical safety of the module and connected devices. This parameter is consistent with the isolation standards of industrial interface components such as 32 channel input modules of the same type.
Interface and signal transmission
Communication adaptation: Combining the mainstream communication protocols of Allen Bradley industrial control systems, this module is likely to support commonly used industrial protocols such as EtherNet/IP or DeviceNet, and can achieve stable data exchange with controllers such as Controllogix and CompactLogix, adapting to the high-frequency signal transmission requirements in industrial scenarios.
Interface characteristics: It is speculated that a standardized rack slot interface will be used to adapt to the slot specifications of Allen Bradley general industrial control cabinet racks, which can achieve seamless docking with power modules and I/O modules inside the rack. The interface terminals of the modules are likely to support 14-18AWG wiring specifications, and the wiring method may be screw fixed connection to ensure wiring stability.
