Bently Nevada 3500/42-04-00｜Proximitor Seismic Monitor｜
Functional Description and Technical Specifications
Sensor compatibility
The module supports both eddy current proximity probes (for shaft vibration and displacement monitoring) and seismic sensors (for casing/shell vibration monitoring). This enables comprehensive condition monitoring of rotating machinery.
Signal processing
Input signals are filtered, amplified, and linearized to achieve high-accuracy measurement with an accuracy of ±0.02 % FS + 2 dB, ensuring stable and reliable data under industrial operating conditions.
Alarm and interlocking functions
Supports multi-level alarm threshold configuration. Based on measured values, the module can trigger alarm or shutdown (trip) signals, meeting the protection requirements of critical equipment.
Fault diagnostics
Provides real-time monitoring of sensor and module status. Fault events are recorded via System 1 software, enabling post-event analysis and predictive maintenance.
System integration
Seamlessly integrates within the Bently Nevada 3500 system and interfaces with external PLC/DCS platforms. Suitable for rotating machinery protection systems in power generation, petrochemical, and metallurgical industries.
Channel Configuration and Measurement Parameters
Channel configuration
4 independent channels
Supports eddy current probes (e.g. 3300 XL) and seismic sensors (acceleration or velocity)
Each channel can be individually configured for the required measurement type
Input sensitivity
Eddy current probes: 3.94 mV/µm (100 mV/mil)
Seismic – acceleration: 10 mV/g
Seismic – velocity: 10 mV/(mm/s)
Measurement ranges
Eddy current measurements:
Radial vibration: 0 – 5000 µm
Axial displacement: 0 – 25.4 mm
Seismic measurements:
Frequency range: 0.1 Hz – 1 kHz
These ranges cover the most common operating scenarios of industrial rotating machinery.
Output signals
4–20 mA per channel
0–10 V per channel
Buffered sensor output
Outputs are fully compatible with PLC/DCS systems and external data acquisition systems.
