General
Parameter Specification
Product Series ControlLogix (Bul. 1756)
Component Type PLC & I/O
Module Type Analog Output Module
Output Channels 8 Analog Outputs
Safety Module No
Analog Output Specifications
Parameter Specification
Output Signal Types Voltage and Current
Voltage Ranges ±10 V, 0…10 V
Current Ranges 0…20 mA, 4…20 mA
Output Resolution 16 bits
Output Update Rate Program dependent
Channel Isolation None (module-level referenced)
Communications & Integration
Parameter Specification
Backplane Communication ControlLogix backplane
Compatible Controllers ControlLogix 1756 / 1757
Configuration Software RSLogix 5000 / Studio 5000 (Logix Designer)
Electrical
Parameter Specification
Backplane Current (5.1 V DC) ~300 mA
Backplane Current (24 V DC) ~0 mA
Power Dissipation ~5.8 W (typical)
Isolation Voltage 250 V continuous (field side to backplane)
Physical
Parameter Specification
Module Slot Width 1 slot
Weight ~0.3 kg
Enclosure Open-type (rack mounted)
Environmental
Parameter Specification
Operating Temperature (Min) 0 °C
Operating Temperature (Max) 60 °C
Storage Temperature (Min) −40 °C
Storage Temperature (Max) 85 °C
Relative Humidity 5…95 % RH, non-condensing
Mechanical Ratings
Parameter Specification
Shock Rating IEC 60068-2-27
Vibration Rating IEC 60068-2-6
Typical Applications

Control valve positioning

VFD or servo analog speed reference

Process control outputs (flow, pressure, temperature loops)

Actuator and transducer control in DCS/PLC systems
